High voltage (11KV) controlling or switching
Protection (Overload, short circuit, earth fault, or any electric fault)
Status reading (Current, voltage, frequency)
The design of the winding supports and spacer enables the windings to withstand the radial as well as loop stress in the outer winding and compressive stress in the inner winding.
|
VCB |
VCB |
LBS |
SF6 |
SF6 |
Max. System Voltage |
12KV |
36KV |
12KV |
121KV |
36 KV |
Rated Current |
6304-1250A |
630-1250A |
630A |
630A-12504 |
630A-1250A |
Short time Current ratings for 3 sec. |
20-25KA |
20KA |
18.1 KA |
20-25KA |
20KA-25KA |
Basic impulse level |
75 KV |
170 KV |
75KV |
75 KV |
170 KV |
Power Frequency Withstand Voltage |
28KV |
70 KV |
28 KV |
28 KV |
70KV |
Frequency |
50Hz |
50Hz |
50Hz |
50Hz |
50Hz |
- Quality Assured
- Competitive Price
- Designed for Engineering Efficiency
- After Sales Service
- Mounting & Moving Facility
